Model No.

YTHB-1210

LCD panel

Size/Aspect ratio

12.1''/4:3

Pixel numbers

800(H)*600(V)

Brightness

1000 cd/m²

Contrast Ratio

700:1

Viewing Angle

160° (H)/140° (V)

Colors

16.2 M

Input terminals

PC signal

D-Sub15 pin*1, DVI*1

Power plug

100-240V AC

OSD Control

Menu, Auto, Up, Down, Power

Operating condition

Temperature

-20°C to 60°C (Operating)

-30°C  to 70°C (Storage )

Humidity

10% RH to 90% RH (Operating)

10% RH to 90% RH (Storage)

Touchscreen (optional)

Vandal-proof 10points projected capacitive

Interface: USB / RS232

Power &

Input Voltage

12V DC,(AC adapter,100~240VAC,50/60Hz)

Power rating

Operation

30 watt

(support DPMS)

Stand-by

‹5 watt

Weight

N.W./G.W.

3.0Kgs/3.8Kgs

External Dimension

　

Mount

Embedded mount, VESA 75mm, wall mount, etc.

Optional

Input: VGA+DVI,VGA+DVI+AV

Touch screen(Resistive,SAW,IR,Capacitive)

PC Mainboard

Speakers

Protect glass(Screen protected,double coating)
